Illustrated parts catalog
3–3
Item
Description
Spare Part Number
(1)
Display assembly (includes 2 WLAN antenna transceivers and cables, webcam, microphones, and logo)
16.0-inch, WXGA, AntiGlare, FHD, dual lamp with webcam and microphone
497936-001
16.0-inch, WXGA, AntiGlare, HD, dual lamp with webcam and microphone
496468-001
16.0-inch, WXGA, AntiGlare, HD, single lamp with webcam and microphone
497937-001
✎
See
“Display assembly components” on page 3-8
for information on display assembly spare part numbers.
(2)
Switch cover
496471-001
(3)
Keyboard cover (includes LED board and cable)
496472-001
(4)
Keyboard (includes cable)
For use in Denmark, Finland, and Norway
508199-DH1
For use in France
496672-051
For use in French Canada
508199-121
For use in Germany
496672-041
For use in Greece
496672-DJ1
For use in Italy
496672-061
For use in Japan
508199-291
For use in Latin America
496672-161
For use in the Netherlands
496672-B31
For use in Russia
496672-251
For use in Saudi Arabia
508199-171
For use in South Korea
508199-AD1
For use in Spain
496672-071
For use in Switzerland
496672-BG1
For use in Taiwan
496672-AB1
For use in Thailand
508199-281
For use in Turkey
496672-141
For use in the United Kingdom
496672-031
For use in the United States
496672-001
(5)
Power button board (includes cable)
496482-001
Plastics Kit, includes:
496477-001
(6a)
ExpressCard slot bezel
(6b)
Hard drive cover
(6c)
WLAN module compartment cover
✎
See
for more Plastics Kit spare part information.
(7)
Bluetooth module
✎
The Bluetooth module spare part kit does not include a Bluetooth module cable.
The Bluetooth module cable is available using spare part number 496461-001.
483113-001
(8)
Bluetooth module cable
496461-001
(Continued)
