Hasselblad H1D
F G H
Hasselblad H1D
Change down button
D
Can alter the settings ‘downwards’. For example, to decrease the film speed setting. Toggle
action.
Function selector
E
Selects the four functions that can be changed on the magazine. e functions are on a menu
loop so that repeated pressing of the selector button will successively access all functions
in turn. Aer a time-out of five seconds of non-activity, the display returns to the standard
screen.
!
Changes can only be made when the settings lock switch is in the unlocked position.
Film plane index
F
Provides a measuring point for the actual position of the film plane in the magazine. Sometimes
used for calculations in critical applications.
Darkslide indicator
G
Indicates whether the darkslide is in place or withdrawn:
RED
= stop !
= exposure CANNOT be made
(magazine can be removed from camera)
WHITE
= ok !
= exposure CAN be made
(magazine cannot be removed from camera)
