6

2.3 Terminal Features

Physical Characteristics
Height

232 mm (11.21 in)

Width

51 mm (2.08 in)

Depth

202 mm (10.41 in)

Net Weight

2.20 kgs (4.85 lbs)

Power Cord

6 ft (1.83m)

Environmental
Operating Temperature

5 to 40

к (41 to 104л)

Non-operating Temperature

-40to 60

к (-40 to 150л)

Operating Humidity

20% to 80%, non-condensing

Operating Altitude

0 to 10,000 ft ASL

Nonoperating Altitude

0 to 40,000 ft ASL

Regulatory
EMC Terminal/Power Brick

FCC B, CE, CB, CUL, C-TICK, BSMI,

Safety Power Brick

UL1950, CB IEC60950.

Installation

2.4 Terminal Overview

2.4.1

Connecting the Terminal

Follow these instructions to connect the terminal to its peripheral devices:

A.

Connect the keyboard to the keyboard connector.

B.

Connect the mouse to the mouse connector.

C.

Connect the 10/100-T network cable to the RJ-45 network connector.

D.

Connect the power cord and the adapter to the power connector with AC outlet.

E.

Connect the power cord to the power connector with AC outlet.
