80
R-09 Configuration Settings
This feature sets peak hold for the Level Meter. When peak hold is ON, the largest value for
the input signal is held and displayed for a set time.
fig.displaysetting-e.eps_80
1.
Select “Display Setup” from the
Use the [PLAY Button ] and [STOP Button ] to select
“Display Setup,” then press the [REC Button].
fig.displaytimer-e.eps_80
2.
Select “Peak Hold.”
Use the [PLAY Button ] and [STOP Button ] to move
the cursor to the Peak Hold line.
fig.setdisplaytimer-e.eps_80
3.
Set Peak Hold.
Use the [RWD Button ] and [FWD Button ] to change
the Peak Hold value.
When finished with the settings, press the [MENU] button to return
to previous screens.
Setting Peak Hold for the Level Meter (Peak Hold)
Setting
OFF (no Peak Hold)
ON (use Peak Hold)
Move the
cursor
up or down
Enter
Move the
cursor
up or down
Change
the value
