38
Recording
fig.level.eps-e_80
Use the [Input Level Button] to adjust the volume so that the [PEAK Indicator] does not light up even
when the loudest sound is produced by the target. Doing this prevents clipping during the loudest
parts of a song or during instrumental passages played fortissimo.
Once the level is set, press the [REC Button] once more to start recording.
• Press the [STOP Button ] to stop recording and return to the
settings are saved, press the [REC Button] again to start recording with the same input level.
• Some noise may be heard when the input level is being adjusted with the [Input Level Buttons]. This is
not a malfunction.
Beyond this level
clipping occurs
Waveforms are clipped
and sound is distorted
Level range
for R-09 recording
Clipped
Input sound
waveform
Recording
waveform
PEAK
Indicator lights up
