94 midi implementation – Edirol V-4 User Manual
Page 94
94
MIDI Implementation
|10H 00H 07H
|V—LINK Auto Mix Mode
|00H — 01H
|Presentation Mode : OFF, ON
|
+————————————————————————————————————————————————————————————————————————————————————————————————+
3-2-2 Clip Control Preference
+————————————————————————————————————————————————————————————————————————————————————————————————————————————————+
|Address
|Parameter Name
|Sys Ex. Value
|Meaning of Value
|
|—————————————————————————————————————————————————————————————————————————————————————————————————————————————————
|#10H 10H 00H
|V—LINK Rx Setting (Playback Speed)
|———
|———
||
|#10H 10H 02H
|V—LINK Rx Setting (Dissolve Time)
|01H—05H, 07H—1FH,
|Transition Time:Control Change |
|
|
|40H—5FH, D0H, E0H, EFH |Channel Press, Pitch Bend, OFF |
|#10H 10H 04H
|V—LINK Rx Setting (Audio Level)
|———
|———
|
|#10H 10H 06H
|V—LINK Rx Setting (T—Bar Control)
|01H—05H, 07H—1FH,
|Video Fader : Control Change,
|
|
|
|40H—5FH, D0H, E0H, EFH |Channel Press, Pitch Bend, OFF |
|#10H 10H 08H
|V—LINK Rx Setting (Dual Stream)
|———
|
|
|#10H 10H 0AH
|V—LINK Reserved
|———
|———
|
|#10H 10H 0CH
|V—LINK Reserved
|———
|———
|
|#10H 10H 0EH
|V—LINK Reserved
|———
|———
|
|#10H 10H 10H
|V—LINK Rx Setting (Transition Select)
|01H—05H, 07H—1FH,
|Control Change,
|
|
|
|40H—5FH, D0H, E0H, EFH |Channel Press, Pitch Bend, OFF |
|#10H 10H 12H
|V—LINK Rx Setting (Transformer A)
|01H—05H, 07H—1FH,
|Control Change,
|
|
|
|40H—5FH, D0H, E0H, EFH |Channel Press, Pitch Bend, OFF |
|#10H 10H 14H
|V—LINK Rx Setting (Transformer B)
|01H—05H, 07H—1FH,
|Control Change,
|
|
|
|40H—5FH, D0H, E0H, EFH |Channel Press, Pitch Bend, OFF |
|#10H 10H 16H
|V—LINK Rx Setting (BPM Sync)
|01H—05H, 07H—1FH,
|Control Change,
|
|
|
|40H—5FH, D0H, E0H, EFH |Channel Press, Pitch Bend, OFF |
+————————————————————————————————————————————————————————————————————————————————————————————————————————————————+
3-2-3 Color COntrol Preference
+————————————————————————————————————————————————————————————————————————————————————————————————————————————————+
|Address
|Parameter Name
|Sys Ex. Value
|Meaning of Value
|
|———————————————————————————————————————————————————————————————————————————————————————————————————————————————---
|#10H 20H 00H
|V—LINK Rx Setting (Color Cb)
|———
|———
|
|#10H 20H 02H
|V—LINK Rx Setting (Color Cr)
|———
|———
|
|#10H 20H 04H
|V—LINK Rx Setting (Brightness)
|———
|———
|
|#10H 20H 06H
|V—LINK Rx Setting (VFX A1)
|01H—05H, 07H—1FH,
|Ach Effect 1 : Control Change, |
|
|
|40H—5FH, D0H, E0H, EFH |Channel Press, Pitch Bend, OFF |
|#10H 20H 08H
|V—LINK Rx Setting (VFX A2)
|01H—05H, 07H—1FH,
|Ach Effect 2 : Control Change, |
|
|
|40H—5FH, D0H, E0H, EFH |Channel Press, Pitch Bend, OFF |
|#10H 20H 0AH
|V—LINK Rx Setting (VFX A3)
|01H—05H, 07H—1FH,
|Ach Effect 3 : Control Change, |
|
|
|40H—5FH, D0H, E0H, EFH |Channel Press, Pitch Bend, OFF |
|#10H 20H 0CH
|V—LINK Rx Setting (VFX A4)
|01H—05H, 07H—1FH,
|Ach Effect 4 : Control Change, |
|
|
|40H—5FH, D0H, E0H, EFH |Channel Press, Pitch Bend, OFF |
|#10H 20H 0EH
|V—LINK Reserved
|———
|———
|
|#10H 20H 10H
|V—LINK Reserved
|———
|———
|
|#10H 20H 12H
|V—LINK Reserved
|———
|———
|
|#10H 20H 14H
|V—LINK Reserved
|———
|———
|
|#10H 20H 16H
|V—LINK Rx Setting (VFX B1)
|01H—05H, 07H—1FH,
|Bch Effect 1 : Control Change, |
|
|
|40H—5FH, D0H, E0H, EFH |Channel Press, Pitch Bend, OFF |
|#10H 20H 18H
|V—LINK Rx Setting (VFX B2)
|01H—05H, 07H—1FH,
|Bch Effect 2 : Control Change, |
|
|
|40H—5FH, D0H, E0H, EFH |Channel Press, Pitch Bend, OFF |
|#10H 20H 1AH
|V—LINK Rx Setting (VFX B3)
|01H—05H, 07H—1FH,
|Bch Effect 3 : Control Change, |
|
|
|40H—5FH, D0H, E0H, EFH |Channel Press, Pitch Bend, OFF |
|#10H 20H 1CH
|V—LINK Rx Setting (VFX B4)
|01H—05H, 07H—1FH,
|Bch Effect 4 : Control Change, |
|
|
|40H—5FH, D0H, E0H, EFH |Channel Press, Pitch Bend, OFF |
|#10H 20H 1EH
|V—LINK Reserved
|———
|———
|
|#10H 20H 20H
|V—LINK Rx Setting (Output Fader)
|01H—05H, 07H—1FH,
|Control Change,
|
|
|
|40H—5FH, D0H, E0H, EFH |Channel Press, Pitch Bend, OFF |
+————————————————————————————————————————————————————————————————————————————————————————————————————————————————+
