Examples of using the V-4
Using the V-4 at a presentation
You can use the V-4 to switch between live images and VTR/DVD output, or add images/text from
a personal computer.
*
If you are using a personal computer that does not have a video output, you will need to use a scan converter to convert
the computer’s VGA output into a video signal.
Live source
PC
DVD
( )
Preview
Large display (plasma)
Projector
Advantages of using the V-4
• Use picture-in-picture to display two screens simultaneously
• Use luminance key to superimpose text or graphics on the image
• Easy operation in Presentation mode
*
For details on using picture-in-picture, refer to p. 26.
*
For details on using luminance key, refer to p. 28.
*
For details on Presentation mode, refer to p. 68.
