MIDI implementation
2. MIDI messages transmitted from MIDI
OUT
* If MIDI Thru is ON, MIDI messages received at MIDI IN are re-transmitted without
change from MIDI OUT.
* If MIDI Thru is ON, messages from the V-4 itself will not be transmitted.
■ Channel voice messages
● Control Change
* The messages assigned in MIDI Setup will be transmitted when you operate the panel.
The control changes that can be used are CC#1--5, 7--31, and 64--95. For the factory
settings, refer to “Settings Transmitted/Received Using MIDI” (p. 95).
❍ Bank Select (controller numbers 0, 32)
Status 2nd byte 3rd byte
---------------------------------------------------------------------
BnH
00H mmH
BnH 20H llH
mm, ll= bank number:
*
When you select channel A or channel B inputs, make memory settings, or specify how
sub-channels are mixed in Presentation mode, these messages will be transmitted in
conjunction with Program Changes.
* The following controls correspond to each Bank Select message.
Bank Select Program No. Control
MSB/LSB
-------------------------------------------------------------------------------
50H/00H
00H - 07H MEMORY 1-8
-------------------------------------------------------------------------------
00H/00H
00H - 03H A ch, INPUT 1-4
-------------------------------------------------------------------------------
01H/00H
00H - 03H B ch, INPUT 1-4
-------------------------------------------------------------------------------
❍ Modulation (controller number 1)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
01H vvH
❍ Breath-type (controller number 2)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
02H vvH
❍ Foot-type (controller number 4)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
04H vvH
❍ Portamento Time (controller number 5)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
05H vvH
❍ Volume (controller number 7)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
07H vvH
❍ Balance (controller number 8)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
08H vvH
❍ Panpot (controller number 10)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
0AH vvH
❍ Expression (controller number 11)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
0BH vvH
❍ Effect Control 1 (controller number 12)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
0CH vvH
❍ Effect Control 2 (controller number 13)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
0DH vvH
❍ General Purpose Controllers 1--4 (controller numbers 16-19)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
10H - 13H vvH
❍ Hold 1 (controller number 64)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
40H xxH
❍ Portamento (controller number 65)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
41H xxH
❍ Sostenuto (controller number 66)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
42H xxH
❍ Soft (controller number 67)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
43H xxH
❍ Legato (controller number 68)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
44H xxH
❍ Hold 2 (controller number 69)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
45H xxH
❍ Sound Controllers 1--10 (controller numbers 70--79)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
46 - 4FH vvH
❍ General Purpose Controllers 5--8 (controller numbers 80--83)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
50 - 53FH vvH
❍ Portamento Control (controller number 84)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
54H vvH
❍ Effect Depth 2--5 (controller number 92--95)
Status 2nd byte 3rd byte
--------------------------------------------------------------------
BnH
5C - 5FH vvH
