Instruction Manual
IB-106-340 Rev. 3.0
December 2003
Rosemount Analytical Inc. A Division of Emerson Process Management Replacement Parts 11-7
Oxymitter 4000
Table 11-3. Replacement Parts for SPS 4000
Figure and Index No. Part Number Description
9-13, 4 1A99093H01 Bushing Gasket
9-15, 19 6292A97H03 Check Valve
9-13, 15 1A99089H01 Cover O-ring
9-15, 17 771B635H01 Flowmeter Assembly, Calibration Gas
9-15, 16 771B635H02 Flowmeter Assembly, Reference Air (Optional)
9-15, 8 1A99094H01 Pressure Regulator, Reference Air (Optional)
9-13, 17 1A97913H03 Fuse, 5A, 250V, 5 × 20 mm, Slow Blow
9-13, 19 4850B56G02 Interface Board
9-13, 18 4850B54G01 Power Supply Board
9-13, 12 7305A67H01 Pressure Switch
9-13, 13 and 20 3D39435G01 Solenoid
9-13, 8 120039-0077 O-ring
9-13, 28 4850B75H01 Terminal Cover Gasket
9-13, 25 1A99147H01 Terminal Strip
Table 11-4. Replacement Parts for Calibration Components
Figure and Index No. Part Number Description
1A99119G01 Calibration Gas Bottles — 0.4% and 8% O
2
, balance
nitrogen — 550 liters each*
1A99119G02 Two Flow Regulators (for calibration gas bottles)
1A99119G03 Bottle rack
*Calibration gas bottles cannot be shipped via airfreight.
