ENGLISH
10
7 7. INSTALLING THE THERMOMETER
Parts Required:
1 x Thermometer Assembly (#1)
Installation:
• Open the lid and unscrew the butterfly nut from
the Thermometer Assembly. Place the Thermometer
Base over the hole on top of the lid. Insert the
Thermometer's pin through the base and lid.
• Hold the Thermometer in place on top of the lid. Place
the washer over the pin on the inside of the lid and
screw the butterfly nut to secure the Thermometer.
• The unit is now completely assembled.
