Elation Professional 15R User Manual
Page 24
24
176-182 Gobo 9 shake slow to fast
183-189 Gobo 10 shake slow to fast
190-196 Gobo 11 shake slow to fast
197-203 Gobo 12 shake slow to fast
204-210 Gobo 13 shake slow to fast
211-217 Gobo 14 shake slow to fast
218-255 Gobo wheel rotation from slow to fast
17
Fixed gobo indexing Fine
17
0-255
Fixed gobo Fine indexing
12
10
18
3 facet rotating prism, Prism / Gobo macros:
12
10
18
0-31
Open
12
10
18
32-127 Rot. Prism
12
10
18
128-135 Macro 1
12
10
18
136-143 Macro 2
12
10
18
144-151 Macro 3
12
10
18
152-159 Macro 4
12
10
18
160-167 Macro 5
12
10
18
168-175 Macro 6
12
10
18
176-183 Macro 7
12
10
18
184-191 Macro 8
12
10
18
192-199 Macro 9
12
10
18
200-207 Macro 10
12
10
18
208-215 Macro 11
12
10
18
216-223 Macro 12
12
10
18
224-231 Macro 13
12
10
18
232-239 Macro 14
12
10
18
240-247 Macro 15
12
10
18
248-255 Macro 16
13
11
19
Rotating prism:
13
11
19
0-127
Prism indexing
13
11
19
128-189 Forwards prism rotation from fast to slow
13
11
19
190-193 No rotation
13
11
19
194-255 Backwards prism rotation from slow to fast
20
Rotating Prism indexing Fine
20
0-255
Fine indexing
14
12
21
Focus :
14
12
21
0-255
Continuous adjustment from near to far
22
Focus Fine:
22
0-255
Continuous adjustment Fine
15
13
23
Zoom :
15
13
23
0-255
Zoom adjustment from small to big
24
Zoom Fine:
24
0-255
Zoom adjustment Fine
Shutter, strobe:
- - XM542-V1.0-NR
