Elation Professional 15R User Manual
Page 23
23
9
7
13
50-59
Rot. gobo 5
9
7
13
60-69
Rot. gobo 6
9
7
13
70-79
Rot. gobo 7
9
7
13
80-89
Rot. gobo 8
9
7
13
90-104 Rot. gobo 1 shake
9
7
13
105-119 Rot. gobo 2 shake
9
7
13
120-134 Rot. gobo 3 shake
9
7
13
135-149 Rot. gobo 4 shake
9
7
13
150-164 Rot. gobo 5 shake
9
7
13
165-179 Rot. gobo 6 shake
9
7
13
180-194 Rot. gobo 7 shake
9
7
13
195-209 Rot. gobo 8 shake
9
7
13
210-255 Rot. gobo wheel cont. rotation slow to fast
10
8
14
Rotating gobo index, rotating gobo rotation :
10
8
14
0-127
Gobo indexing
10
8
14
128-189 Forwards gobo rotation from fast to slow
10
8
14
190-193 No rotation
10
8
14
194-255 Backwards gobo rotation from slow to fast
15
Rotating gobo indexing Fine
15
0-255
Fine indexing
11
9
16
Fixed Gobos :
11
9
16
0-7
Open/hole
11
9
16
8-15
Gobo 1
11
9
16
16-23
Gobo 2
11
9
16
24-31
Gobo 3
11
9
16
32-39
Gobo 4
11
9
16
40-47
Gobo 5
11
9
16
48-55
Gobo 6
11
9
16
56-63
Gobo 7
11
9
16
64-71
Gobo 8
11
9
16
72-79
Gobo 9
11
9
16
80-87
Gobo 10
11
9
16
88-95
Gobo 11
11
9
16
96-103 Gobo 12
11
9
16
104-111 Gobo 13
11
9
16
112-119 Gobo 14
11
9
16
120-126 Gobo 1 shake slow to fast
11
9
16
127-133 Gobo 2 shake slow to fast
11
9
16
134-140 Gobo 3 shake slow to fast
11
9
16
141-147 Gobo 4 shake slow to fast
11
9
16
148-154 Gobo 5 shake slow to fast
11
9
16
155-161 Gobo 6 shake slow to fast
11
9
16
162-168 Gobo 7 shake slow to fast
11
9
16
169-175 Gobo 8 shake slow to fast
- - XM542-V1.0-NR
