A-2 Appendix
Token Ring STP Pinout - Female-DB9
− NETQue Token Ring
1
Receive /R1
2
No Connection
3
No Connection
4
No Connection
5
Transmit/B5
6
Receive/G6
7
No Connection
8
No Connection
9
Transmit/09
Serial Connector Pinout - Male DB9 (DTE)
− NETQue
− NETQue Pro2
− NETQue Token Ring
1 DCD
Data Carrier Default
2 RXD
Receive Data
3 TXD
Transmit Data
4 DTR
Data Terminal Ready
5 GND
Ground
6 DSR
Data Set Ready
7 RTS
Request To Send
8 CTS
Clear To Send
9 RI
Ring Indicator
