EATON Powerware ® 9315 UPS (500–750 kVA) Installation and Operation Manual S 164201691 Rev 1 www.powerware.com 6-1
Chapter 6 Installing Optional Accessories
This chapter contains installation information for the following options:
S Monitoring accessories: Remote Monitor Panel (RMP), Relay Interface Module
(RIM), and Supervisory Contact Module (SCM)
S X-Slot cards
NOTE When installing interface connections (such as an RMP, RIM, or SCM), install conduit between each
device and the UPS cabinet.
A maximum of two monitoring accessories (RMPs, RIMs, or SCMs) can be installed.
An X-Slot card can also be installed with the monitoring accessories. See Table 6-1 for
the number of accessories permitted.
Table 6-1. Optional Monitoring Accessories
Number and Type of Accessories Permitted
RMP RIM SCM X-Slot
2 — — 1
— 2 — 1
— — 2 1
1 1 — 1
1 — 1 1
— 1 1 1
