INSTALLATION REFERENCE
EATON Powerware ® 9315 UPS (500–750 kVA) Installation and Operation Manual S 164201691 Rev 1 www.powerware.com A-14
Table F. Input/Output Ratings and External Wiring Requirements (PW9315-700/500 and PW9315-750/562)
Basic Unit Rating
PW9315 750/500 0 8 L i F L d
Units Rating 50/60 Hz
PW9315-750/500 at 0.8 Lagging pF Load
PW9315-750/562 at 0.9 Lagging pF Load
kVA/kW 625/500 625/500 625/562 625/562
Input and Output Voltage Volts 480 600 480 600
AC Input to UPS Rectifier (0.95 Min. pF)
(3) Phases, (1) Neutral, (1) Ground
Amps* 951 761 984 787
Minimum Conductor Size
Number per Phase
* Maximum amps includes full load current plus
battery recharge current A
AWG or kcmil
(each)
400
(4)
350
(4)
500
(4)
350
(4)
AC Input to MBC (UPS Bypass)
Full Load Current
(3) Phases, (1) Neutral, (1) Ground
B
Amps 752 601 752 601
Minimum Conductor Size
Number per Phase
B
AWG or kcmil
(each)
500
(3)
350
(3)
500
(3)
350
(3)
DC Input from Battery to UPS
(1) Positive, (1) Negative
C
Vdc
Amps @ (2.0V/cell)
480
1096
480
1096
480
1234
480
1234
Minimum Conductor Size
Number per Pole
C
AWG or kcmil
(each)
400
(4)
400
(4)
500
(4)
500
(4)
AC Output to Optional SBM
Full Load Current
(3) Phases, (1) Neutral, (1) Ground
E
Amps 752 601 752 601
Minimum Conductor Size
Number per Phase
E
AWG or kcmil
(each)
500
(3)
350
(3)
500
(3)
350
(3)
AC Output to Critical Load
Full Load Current
(3) Phases, (1) Neutral, (1) Ground
D
Amps 752 601 752 601
Minimum Conductor Size
Number per Phase
D
AWG or kcmil
(each)
500
(3)
350
(3)
500
(3)
350
(3)
NOTE Callout letters A, B, C, D, and E map to Figure A-8.
