Customer Interface Wiring Notes
1.
Use Class 1 wiring methods (as defined by the NEC) for control wiring. Install
the control wiring in separate conduit from the power wiring. The wire should
be rated at 24V, 1A minimum.
2.
See Table O through Table Q and Figure A-18 through Figure A-30 for
customer interface wiring.
Table O. Input/Rectifier Cabinet Customer Interface Connections
CUSTJ4 Terminal
Name
Description
1
Open Filter
D
t
t
d t d
ti
t i
t filt
2
Open Filter Return
Dry contact used to deactivate input filter.
3
No Sync
D
t
t
d t d
ti
t UPS
h
i ti
t b
4
No Sync Return
Dry contact used to deactivate UPS synchronization to bypass.
5
On Generator
D
t
t
d t i di
t UPS i b i
li d
b th
t
6
On Generator Return
Dry contact used to indicate UPS is being supplied power by the generator.
7
Battery Disconnect Open
D
t
t
d t i di
t UPS B tt
Di
t i
8
Battery Disconnect Open Return
Dry contact used to indicate UPS Battery Disconnect is open.
9
Not Used
10
Not Used
CB2TB Terminal
Name
Description
1
Not Used
2
CB2 Close - 120 Vac
Close circuit breaker CB2 signal.
3
CB2 - AUX #1
Ci
it b
k
CB2
ili
t
t
4
CB2 - AUX #1
Circuit breaker CB2 auxiliary contact.
5
Not Used
6
Not Used
7
Control - 120 Vac
B
k
h
8
Control - Neutral
Breaker charge power.
9
Shunt Trip - 24 Vdc
O
i
it b
k
CB2 i
l
10
Shunt Trip - 24 Vdc
Open circuit breaker CB2 signal.
