Table P. Output/Inverter Cabinet Customer Interface Connections
CUSTJ4 Terminal Name Description
1 Building Alarm 2
P bl UPS l A ti t d b t d t t l
2 Building Alarm 2 Return
Programmable UPS alarm. Activated by a remote dry contact closure.
3 Building Alarm 3
P bl UPS l A ti t d b t d t t l
4 Building Alarm 3 Return
Programmable UPS alarm. Activated by a remote dry contact closure.
5 Building Alarm 4
P bl UPS l A ti t d b t d t t l
6 Building Alarm 4 Return
Programmable UPS alarm. Activated by a remote dry contact closure.
7 Building Alarm 5
P bl UPS l A ti t d b t d t t l
8 Building Alarm 5 Return
Programmable UPS alarm. Activated by a remote dry contact closure.
9 Not Used
10 Not Used
CUSTJ2 Terminal Name Description
1 Relay 1 NC
2 Relay 1 Commom General purpose normally-open and normally-closed relay contacts.
3 Relay 1 NO
p p y p y y
4 Building Alarm 1
P bl UPS l A ti t d b t d t t l
5 Building Alarm 1 Return
Programmable UPS alarm. Activated by a remote dry contact closure.
6 Relay 2 NC
7 Relay 2 Common General purpose normally-open and normally-closed relay contacts.
8 Relay 2 NO
p p y p y y
9 Not Used
10 Not Used
CUSTTB Terminal Name Description
1 CB3 - Aux #2
Ci it b k CB3 ili t t
2 CB3 - Aux #2*
Circuit breaker CB3 auxiliary contact.
3 Not Used
4 Remote to Bypass
D t t d t ti t t t f t b
5 Remote to Bypass Return
Dry contact used to activate remote transfer to bypass.
6 Remote to UPS
D t t d t ti t t t f t UPS
7 Remote to UPS Return
Dry contact used to activate remote transfer to UPS.
8 Not Used
9 REPO
D t t d t ti t REPO f UPS
10 REPO Common
Dry contact used to activate REPO of UPS.
