INSTALLATION REFERENCE
EATON Powerware ® 9315 UPS (500–750 kVA) Installation and Operation Manual S 164201691 Rev 1 www.powerware.com A-15
Table G. Input/Output Ratings and External Wiring Requirements (PW9315-750/600 and PW9315-750/675)
Basic Unit Rating
PW9315 750/600 0 8 L i F L d
Units Rating 50/60 Hz
PW9315-750/600 at 0.8 Lagging pF Load
PW9315-750/675 at 0.9 Lagging pF Load
kVA/kW 750/600 750/600 750/675 750/675
Input and Output Voltage Volts 480 600 480 600
AC Input to UPS Rectifier (0.95 Min. pF)
(3) Phases, (1) Neutral, (1) Ground
Amps* 1141 913 1181 945
Minimum Conductor Size
Number per Phase
* Maximum amps includes full load current plus
battery recharge current A
AWG or kcmil
(each)
700
(4)
500
(4)
700
(4)
500
(4)
AC Input to MBC (UPS Bypass)
Full Load Current
(3) Phases, (1) Neutral, (1) Ground
B
Amps 902 722 902 722
Minimum Conductor Size
Number per Phase
B
AWG or kcmil
(each)
400
(4)
500
(3)
400
(4)
500
(3)
DC Input from Battery to UPS
(1) Positive, (1) Negative
C
Vdc
Amps @ (2.0V/cell)
480
1315
480
1315
480
1480
480
1480
Minimum Conductor Size
Number per Pole
C
AWG or kcmil
(each)
600
(4)
600
(4)
700
(4)
700
(4)
AC Output to Optional SBM
Full Load Current
(3) Phases, (1) Neutral, (1) Ground
E
Amps 902 722 902 722
Minimum Conductor Size
Number per Phase
E
AWG or kcmil
(each)
400
(4)
500
(3)
400
(4)
500
(3)
AC Output to Critical Load
Full Load Current
(3) Phases, (1) Neutral, (1) Ground
D
Amps 902 722 902 722
Minimum Conductor Size
Number per Phase
D
AWG or kcmil
(each)
400
(4)
500
(3)
400
(4)
500
(3)
NOTE Callout letters A, B, C, D, and E map to Figure A-8.
