INSTALLATION REFERENCE
EATON Powerware ® 9315 UPS (500–750 kVA) Installation and Operation Manual S 164201691 Rev 1 www.powerware.com A-34
Table Q. MBC Customer Interface Connections
CUSTJ4 Terminal Name Description
1 Building Alarm 2
P bl UPS l A ti t d b t d t t l
2 Building Alarm 2 Return
Programmable UPS alarm. Activated by a remote dry contact closure.
3 Building Alarm 3
P bl UPS l A ti t d b t d t t l
4 Building Alarm 3 Return
Programmable UPS alarm. Activated by a remote dry contact closure.
5 Building Alarm 4
P bl UPS l A ti t d b t d t t l
6 Building Alarm 4 Return
Programmable UPS alarm. Activated by a remote dry contact closure.
7 Building Alarm 5
P bl UPS l A ti t d b t d t t l
8 Building Alarm 5 Return
Programmable UPS alarm. Activated by a remote dry contact closure.
9 Not Used
10 Not Used
CUSTJ2 Terminal Name Description
1 Relay 1 NC
2 Relay 1 Common General purpose normally-open and normally-closed relay contacts.
3 Relay 1 NO
p p y p y y
4 Building Alarm 1
P bl UPS l A ti t d b t d t t l
5 Building Alarm 1 Return
Programmable UPS alarm. Activated by a remote dry contact closure.
6 Relay 2 NC
7 Relay 2 Common General purpose normally-open and normally-closed relay contacts.
8 Relay 2 NO
p p y p y y
9 Not Used
10 Not Used
CUSTTB Terminal Name Description
1 CB3 - Aux #2
Ci it b k CB3 ili t t
2 CB3 - Aux #2*
Circuit breaker CB3 auxiliary contact.
3 Not Used
4 CB4- Aux #2
Ci it b k CB4 ili t t
5 CB4- Aux #2*
Circuit breaker CB4 auxiliary contact.
6 Not Used
7 Not Used
8 Not Used
9 REPO
D t t d t ti t REPO f UPS
10 REPO Common
Dry contact used to activate REPO of UPS.
