ZENMUSE XT 2 User Manual
ROI set to “Full” Sky excluded from ROI
Palette
The Zenmuse XT 2 offers a variety of palette options. Distinct colors are used to show
temperature differences in the thermal image, which are related to grayscale intensity. The
temperature range of the image is mapped to 256 colors and displayed in the 8-bit JPEG or
MPEG-4, MOV format.
The following table shows all palette options.
