ZEUS Technical Manual About this manual
© 2007 Eurotech Ltd Issue D 14
About this manual
This manual describes the operation and use of the ZEUS single board computer. It is
designed to be a reference and user manual and includes information about all aspects
of the board.
Conventions
Symbols
The following symbols are used in this guide:
Symbol Explanation
Note - information that requires your attention.
Tip - a handy hint that may provide a useful alternative or save time.
Caution – proceeding with a course of action may damage your
equipment or result in loss of data.
Jumper is fitted.
Jumper is not fitted.
3
2
1
Jumper fitted on pins 1-2.
3
2
1
Jumper fitted on pins 2-3.
