HP Z32 31.5" 16:9 4K UHD IPS Display (Smart Buy) User Manual

Page 13

background image

●

For a USB Hub:
Connect the Type-C end of a USB cable to a USB Type-C port on the monitor and the other end to a

USB Type-A port on the source device.

●

For DisplayPort Alt-mode:
Connect the Type-C end of a USB cable to a USB Type-C port on the monitor and the other end to a

USB Type-C port on the source device.

NOTE:

To set the video input source to USB-C, press the

Menu

button on the monitor’s rear panel,

select Input Control, and then select USB-C Configuration.

●

Select the option 3840 × 2160 @ 60 Hz + USB 2.0 for a higher vertical refresh rate and a lower USB

speed.
–or–

●

Select the option 3840 × 2160 @ 30 Hz + USB 3.0 for a lower vertical refresh rate and a higher USB

speed.

Setting up the monitor

7
