Appendix, Specification, Figures of installation dimensions – Epson Lighting Track Mount for LightScene EV-105 (Black) User Manual
Page 19
Appendix
18
Specification
Item
Specification
Weight (stopper unit, plate unit, rotating unit, stopper
cover)
Approx. 0.7 kg (1.5 lb)
Maximum load capacity
Approx. 5.9 kg (13 lb)
Exterior color
ELPMB54W: White
ELPMB54B: Black
Figures of Installation Dimensions
The following provides the dimensions for the EV-100/105.
[Unit: mm/inches]
541.7 / 21.3
150 / 5.9
Width of top of projector
Vertical width of top of projector
440.5 / 17.3
45.8 / 1.8
20 / 0.8
