Specifications

GENERAL

Oscillator Type

Crystal-controlled PLL synthesizer

Antenna Type

1/4 λ wavelength wire antenna

Carrier Frequencies

14UC : 470.125 MHz to 541.875 MHz(UHF-TV
channels 14 to 25)
25UC : 536.125 MHz to 607.875 MHz (UHF-TV
channels 25 to 36)
42LA : 638.125 MHz to 697.875 MHz(UHF-TV
channels 42 to 51)
90UC : 941.625 MHz to 951.875 MHz, 953.000
MHz to 956.125 MHz, and 956.625 MHz to
959.625 MHz
21CE : 470.025 MHz to 542.000 MHz(UHF-TV
channels 21 to 29)
33CE : 566.025 MHz to 630.000 MHz(UHF-TV
channels 33 to 40)
42CE : 638.025 MHz to 694.000 MHz (UHF-TV
channels 42 to 48)
38CN : 710.025 MHz to 782.000 MHz(UHF-TV
channels 38 to 46)
E : 794.125 MHz to 805.875 MHz
BJ: 806.125 MHz to 809.750 MHz
KR : 925.125 MHz to 937.500 MHz

RF Output Power

30 mW/5 mW selectable (UC, U, CE, LA, CN
models)
10 mW/2 mW selectable (J, E, KR models)

Capsule Type

Electret condenser

Directivity

Omni-directional

Input Connector

3.5mm diameter 3-pole locking mini jack

Reference Audio Input Level

–60 dBV (MIC input, GAIN MODE set to
NORMAL, 0 dB attenuation)
+4 dBu (LINE input)

Audio Attenuator Adjustment
Range

0 dB to 27 dB (3dB steps)

Frequency Response

23 Hz to 18 kHz (Typical) (UC, U, CE, LA, CN, E,
KR models)
40 Hz to 15 kHz (Typical) (J model)

Signal-to-Noise Ratio

60 dB (–60 dBV, 1 kHz input)
102 dB (GAIN MODE set to AUTO GAIN, max.)
96 dB (GAIN MODE set to NORMAL, max.)

Distortion

0.9% or less (–60 dBV, 1 kHz input)

Audio Delay

Approx. 0.35 ms

Tone Signal Frequency

In UWP-D compander mode: 32.382 kHz
In UWP compander mode: 32 kHz
In WL800 compander mode: 32.768 kHz
