Specifications
A
ppen
dix
Specifications
General
Recording format
MPEG4 SStP format
Power requirements
100 V to 240 V AC
Power consumption
Maximum 480 W
Inrush current
(1) Maximum possible inrush current at initial switch-
on (Voltage changes caused by manual
switching):
75 A peak, 5 A r.m.s. (240 V AC)
(2) Inrush current after a mains interruption of five
seconds (Voltage changes caused at zero-
crossing):
4 A peak, 2 A r.m.s. (240 V AC)
Operating temperature
5 °C to 40 °C (41 °F to 104 °F)
Storage temperature
–20 °C to +60 °C (–4 °F to +140 °F)
Humidity 25% to 90% (no condensation)
Mass 23 kg (50 lb 11 oz) (with all options
installed)
Dimensions 427 Ч 174 Ч 540 mm
(16
7
/
8
Ч 6
7
/
8
Ч 21
5
/
16
in) (W/H/D)
Video
422 format
Sampling frequency
Y: 74.25 MHz,
Pb/Pr: 37.125 MHz
Quantization 10 bits
Compression MPEG4 SStP
444 format
Sampling frequency
RGB: 74.25 MHz
Quantization 10 bits
Compression MPEG4 SStP
Audio
Digital audio signal format
Sampling frequency
48 kHz (video sync)
Quantization 24 bits
Headroom 20 dB / 18 dB (selectable)
Analog monitor output
D/A quantization
24 bits
Input/Output Connectors
When the SRK-R201 is installed (optional)
HD SDI INPUT
A/B BNC (2)
HD SDI (1.485 Gbps) (SMPTE-292M /
BTA-S004B standard)
3G SDI (2.97 Gbps) (SMPTE-424M)
INPUT MONITOR
BNC (2)
HD SDI (1.485 Gbps) (SMPTE-292M /
BTA-S004B standard)
3G SDI (2.97 Gbps) (SMPTE-424M)
HD SDI OUTPUT
MULTI MONITOR
BNC (1)
HD SDI (1.485 Gbps) (SMPTE-292M /
BTA-S004B standard)
TIMECODE INPUT
BNC (1)
0.5 to 18 Vp-p, 10 k
Ω
TIMECODE OUTPUT
BNC (1)
2.2 Vp-p, low impedance
DIGITAL AUDIO (AES/EBU) INPUT
BNC (8)
CH1/2 to CH15/16
AES/EBU format, unbalanced
