Adjustment Using the Menus
24
[On Screen Tally Setting]
[Parallel Remote] menu
[Security] menu
Submenu Setting
[Tally Bckgnd
Display] The tally is displayed on the screen of
this unit.
When [Tally Bckgnd Display] is set to
[On], the mat is displayed on the tally
display area. When [Off], the tally is
displayed directly on the video signal.
Submenu Setting
[1Pin] to [4Pin],
[6Pin] to [8Pin] Selects the PARALLEL REMOTE
connector pins for which you want to
change the function.
You can assign various functions to pins
1 to 4 and pins 6 to 8. The following lists
the functions you can assign to the pins.
 [SDI1]
 [SDI2]
 [HDMI]
 [Composite]
 [80% Area Marker]
 [85% Area Marker]
 [88% Area Marker]
 [90% Area Marker]
 [93% Area Marker]
 [95% Area Marker]
 [Center Marker]
 [4:3 Marker]
 [Side by Side]
 [Tally Red]
 [Tally Green]
 [Normal Scan]
 [Native Scan]
 [4:3]
 [16:9]
 [Flip H]
 [Flip V]
 [Flip H/V]
 [WFM/ALM/Vector]
 [Focus Assist]
 [Mono]
 [Blue Only]
 [– – –] ([– – –]: No function is
assigned.)
Notes
 If you use the parallel remote
function, you need to connect
cables. For more details, see page 11.
 Set [Marker] (page 21) in [Marker
Setting] to [On] to control the aspect
marker and center marker.
Submenu Setting
[Key Inhibit] You can lock the setting so that they
cannot be changed by an unauthorized
user. Select [On] or [Off].
If you set to [On], all items are
displayed in black, indicating the items
are locked.
