Introduction
Welcome to Samson AirLine, the original micro-wireless microphone systems. Wireless
microphone and instrument systems were originally developed to eliminate cables, providing
unparalleled freedom of movement. AirLine ATX takes this concept to a new level with
frequency agile transmitters and micro receiver, providing a completely “hassle-free” user
experience.
Designed to be an extension of your instrument rather than a separate component, the ATX
Wireless Transmitter clips directly to your instrument bell with no cable necessary and lets you
rule the stage with confidence. It provides up to 8 hours of continuous use with the internal
lithium ion rechargeable battery.
The system includes the HM60 condenser microphone with 3-point halo isolation mount to
minimize any noise caused by mechanical vibration. The mic capsule offers a supercardioid
pickup pattern that handles up to 125dB SPL, ideal for handling the sudden attack of wind
instruments. The HM60 also offers an 8.5” adjustable gooseneck (with P3 connector) for
optimal mic placement in front of your instrument’s bell.
Offering frequency-agile UHF operation, the micro-sized True RF Diversity AR99m receiver
provides 100 available channels to secure reliable wireless performance. The receiver provides
easy setup with 1-touch scan which analyzes and selects the clearest operating channel,
infrared set to pair the transmitter with the receiver, and versatile output connections (XLR,
1/4” and 1/8”). An included USB port can be used to charge the ATX transmitter or integrate a
Samson XPD Series wireless system (sold separately) to make it a dual-receiver.
In these pages, you’ll find a detailed description of the features of the AirLine AWXm System,
as well as step-by-step instructions for its setup and use. If your wireless system was purchased
in the United States, you’ll also find a registration card enclosed—don’t forget to follow the
instructions so that you can receive online technical support and so that we can send you
updated information about this and other Samson products in the future. Also, be sure to check
out our website www.samsontech.com for complete information about our full product line.
We recommend you keep the following records for reference, as well as a copy of your sales
receipt:
Receiver Serial number: _________________________________________
Transmitter Serial number: ______________________________________
Date of purchase: ______________________________________________
If you have any questions or comments regarding the AirLine AWXm system or any other
products from Samson, do no hesitate to contact us at
With proper care and maintenance, your AirLine AWXm System will operate trouble-free for many
years. Should your AirLine AWXm system ever require servicing, a Return Authorization (RA) number
must be obtained before shipping your unit to Samson. Without this number, the unit will not be
accepted. Please visit
www.samsontech.com/ra for an RA number prior to shipping your unit. Please
retain the original packing materials and, if possible, return the unit in its original carton. If your
AirLine AWXm system was purchased outside of the United States, contact your local distributor for
warranty details and service information.
