32 | Specifications
Measurement range 0 to 150% R (reflection)
Repetition precision Max 0.2 dE cmc (white tile)
Max 0.8 dE cmc (black tile)
Instrument error Ave 0.5 dE cmc (12BCRA tile ILS20EP standard)
Ave 1.0 dE cmc (12BCRA tile ILS20EP standard)
Electrical
Rated voltage AC 100 to 240 V
Input voltage range AC 90 to 264 V
DC output
(for ILS20EP/ILS20EPUV) 5.5 V 1.0 A
Rated frequency range 50 to 60 Hz
Input frequency range 49.5 to 60.5 Hz
Rated current 44" SpectroProofer:
24" SpectroProofer: 0.3 A/100 V
0.25 A/100 V
Power consumption 44" SpectroProofer:
24" SpectroProofer:
Approx. 10.5 W
Approx. 5.0 W in
Ready Mode
Approx. 3.5 W in
Sleep Mode
Approx. 8.5 W
Approx. 5.0 W in
Ready Mode
Approx. 3.5 W in
Sleep Mode
Standards and approvals
Safety UL60950-1
CAN/CSA-C22.2 No.60950-1
EMC FCC Part 15 Subpart B Class B
CAN/CSA-CEI/IEC CISPR 22 Class B
Spectrophotometer (continued)
