MULTI/PIP menu
Function
Command Direction
Parameter
Reply
Control/Response contents
*
ENLARGE
ENLG
WR
0-1
0-1 0: OFF, 1: ON
-
ENLARGE MODE
EMHV
WR
11-55
11-55 1 x 1 (OFF) to 5 x 5 (“m x n” is expressed as “mn”, where m and n are the
numbers of monitors specified for the longest direction and the shortest direction
respectively.)
IMAGE POSITION (M x N)
EPHV
WR
11-55
11-55 Specifies values in the order of IMAGE POSITION IN LONGEST/ SHORTEST
DIRECTION.
BEZEL ADJUST
BZCO
WR
0-1
0-1 0: OFF, 1: ON
ENLARGE/IMAGE POSITION SETTING ESHV
WR
XXYY
XXYY XX: ENLARGE MODE (Same as EMHV), YY: IMAGE POSITION (Same as
EPHV)
PIP MODES
MWIN
WR
0-3
0-3 0: OFF, 1: PIP, 2: PbyP, 3: PbyP2
PIP SIZE
MWSZ
WR
0-2
0-2 0: SMALL, 1: MIDDLE, 2: LARGE
○
PIP POS
THE LONGEST
DIRECTION
MHPS
W
0-100
R
0-100
THE SHORTEST
DIRECTION
MVPS
W
0-100
R
0-100
PIP POS LD+SD BATCH
MPOS
W
0-100,0-100
Specify the position in MPOSxxxyyy format.
(xxx: Longer side, yyy: Shorter side position)
R
0-100,0-100 Returns a response in (xxx,yyy) format.
(xxx: Longer side, yyy: Shorter side position)
PIP SOURCE
MWIP
WR
1
1 DVI-D
2
2 D-SUB
3
3 COMPONENT
4
4 VIDEO
9
9 HDMI
14
14 DisplayPort
SOUND CHANGE
MWAD
WR
1-2
1-2 1: MAIN, 2: SUB
OTHERS menu
Function
Command Direction
Parameter
Reply
Control/Response contents
*
SCREEN MOTION
MTIM
WR
0-900
0-900 0: OFF, 10-900: Operating interval (Per 10 senconds)
○
POWER MANAGEMENT
(DisplayPort, HDMI, DVI-D, D-SUB)
PMNG
WR
0-1
0-1 0: OFF, 1: ON
POWER MANAGEMENT
(COMPONENT, VIDEO)
PMAV
WR
0-1
0-1 0: OFF, 1: ON
LOGO SCREEN
BTSC
WR
0-1
0-1 0: OFF, 1: ON
SCAN MODE
SCAN
WR
0-1
0-1 0: OVERSCAN, 1: UNDERSCAN
(When the input mode is HDMI)
-
BACKLIGHT OFF
BOMD
W
0-1
0: Enters BACKLIGHT OFF mode, 1: Exits BACKLIGHT OFF mode
R
0-1 0: BACKLIGHT OFF mode, 1: Normal operation state
COLOR SYSTEM (VIDEO)
CSYS
WR
0-5
0-5 0: AUTO, 1: PAL, 2: PAL-60, 3: SECAM, 4: NTSC3.58, 5: NTSC4.43
○
Initialization/Functional Restriction Setting (FUNCTION) menu
Function
Command Direction
Parameter
Reply
Control/Response contents
*
ALL RESET
RSET
W
1
1: ALL RESET
-
ADJUSTMENT LOCK
ALCK
WR
0-1
0-1 0: OFF, 1:ON
○
OSD DISPLAY
LOSD
WR
0-1
0-1 0: ON, 1: OFF
LED
OFLD
WR
0-1
0-1 0: ON, 1: OFF
