Page 8 QTS- CLX-PVX September 2009
Summary of Operations
The following is a short summary of the steps typically followed. Refer to the
appropriate manual section for details.
Step Operation See page
1 Install the QTS-CLX-PVX module in the
ControlLogix chassis 4
2 Set the module mode to monitor (the default) 15
3 Connect the module to the Control I/O bus 7
4 Autoconfigure the module from the PROVOX
Control I/O bus 16
5 Configure the module in RSLogix 5000 10
6 Decide if you are going to use monitor mode to
develop and test your application 28
7 Disconnect the PROVOX master
8 Change the module mode to master 15
9 Save the configuration and download it to the
module 19
10 Create aliases for RSLogix 5000 21
11 Import the aliases into RSLogix 5000 21
12 Use the aliases to access data
