Interface Description
Power Jack
The input power is DC 12V, 2A.
Note: ONLY use package power adapter supplied with the
internet. Otherwise, the product may be damaged.
Network
(RJ-45 LAN
socket)
Connect to PC or Hub/Switch.
For connect to 10Base-T Ethernet or 100Base-TX Fast Ethernet
cabling. This Ethernet port built auto-negotiation protocol can
detect or negotiate the transmission speed of the network
automatically. Please use CAT-5 cable to connect the Network
Camera to a 100Mbps Fast Ethernet network switch or hub.
Note: ONLY use one power source, either from DC or from
802.3af Power over Ethernet.
Line Out
(Green) Connect a loud speaker to the IP Camera. This is for voice
alerting and two-way audio.
Microphone
Input (Pink)
Connect a microphone to the IP Camera.
Video Output
(BNC) Connect Video BNC connector to a TV set if necessary (to check
camera viewing angle and focus).
GPIO
The 6 pin terminal block includes 1 input ports and 1 output
ports.
Terminal block for I/O connectors:
Name Pin Description
Common 1
Digital output implementation; Pin2 to COM (Pin1) is a
Photo-coupled relay on Normal Open status. External
device can directly connect to the terminals. However the
current that will go through the 2 nodes must not exceed
130mA. An external “Relay” can also be connected to the
terminals as an implementation. In this case, current (or/
and voltage) limitation is specified by the external Relay.
RELAY_NO 2
DGND 3 Connect to GND to activate, or leave floating (or
unconnected) to deactivate.
DIGI Input 4
DGND 5
PIN with a short wire connecting two revert to factory
default settings.
Load default 6
