PLANET IVS-2120 - Manual (Page 70)

Industrial Internet Video Server
User’s Manual of IVS-2120
6.14.3. HTTP Server
The device also can send event message to specified HTTP server.
Name User can specify multiple HTTP servers as he wishes.
Therefore, user needs to specify a name for each HTTP server
setting.
URL Type the server name or the IP address of the HTTP server.
Test Check the HTTP server as to whether it is available or not.
HTTP Login Name Type the user name for the HTTP server.
HTTP Login Password Type the password for the HTTP server.
Proxy Address Type the server name or the IP address of the HTTP Proxy.
Proxy Login Name Type the user name for the HTTP Proxy.
Proxy Login Password Type the password for the HTTP Proxy.
Proxy Port Set port number of Proxy.
6.14.4. SAMBA Server
The device also can send video stream to specified SAMBA server. Most of the time, the
SAMBA server will be another PC or NAS server.
