User’s Manual of BSP-300
32
Appendix C:
Recommended Settings for
Different Batteries
Description Specification
Battery type
Nickel-cadmium Battery
System Model
24V
Maximum input voltage
DC 45 V
Output voltage for Load
Equal to battery’s voltage
Float charge voltage
DC 27.2V ( 26.0~30.0V )
Absorption charge voltage
DC 29.2V (28.0~32.0V)
LVD(Low Voltage Disconnection)
DC 22.2V (21.0~25.0V )
LVR(Low Voltage Reconnection)
DC 24.8V (23.0~27.0V )
Temperature compensation
Beseline@25°C
+-40 mV/°C for NiCad type batteries, Charge cut-off @ 55°C
Battery type
Lead-acid batteries (Default Setting)
System Model
24V
Maximum input voltage
DC 45 V
Output voltage for Load
Equal to battery’s voltage
Float charge voltage
DC 27.2V ( 26.0~30.0V )
Absorption charge voltage
DC 29.2V (28.0~32.0V)
LVD(Low Voltage Disconnection)
DC 22.2V (21.0~25.0V )
LVR(Low Voltage Reconnection)
DC 24.8V (23.0~27.0V )
Temperature compensation
Beseline@25°C
+-60 mV/°C for lead acid type batteries, Charge cut-off @ 55°C
