PARTS LIST
7-2
November 1999
Part No. 001-7780-500
IC 1 LC75834W 022-3907-015
J 1 52204-2990 022-3906-128
J 2 AXN820735 022-3906-132
MP 01 10-key front panel (plastic) 022-3907-058
3-key front panel (plastic) 022-3907-087
MP 04 10-key rubber keypad 022-3907-077
3-key rubber keypad 022-3907-089
MP 06 1125 sp rubber-1 (10-key) 022-3906-270
1121 mic seal-1 (3-key) 022-3907-090
MP 07 1125 LCD holder 022-3906-227
MP 08 1591 front plate-1 022-3907-059
MP 09 Screw ph no.0b01.4x4.5ni 022-3906-266
MP 10 Screw ph b0 #.0-3 m1.4x3.5 blk 022-3906-214
MP 11 1125 front seal 022-3906-239
MP 12 Screw b0 2x4 ni (bt) 022-3906-213
MP 15 1125 display plate (10-key) 022-3906-243
1591 display plate (3-key) 022-3907-088
MP 16 Sponge (cp) srcn 022-3906-269
Q 1 2SA1576 S transistor 022-3906-029
Q 2 2SA1576 S transistor 022-3906-029
Q 3 2SA1576 S transistor 022-3906-029
Q 4 2SA1576 S transistor 022-3906-029
R 01 ERJ3GEYJ 103V resistor 022-3906-163
R 02 EFJ3GEYJ 151 V resistor 022-3906-145
R 03 ERJ3GEYJ 332 V resistor 022-3906-159
R 07 NTCCM16084LH 473KC resistor 022-3907-053
R 08 ERJ3GEYJ 473 V resistor 022-3906-171
R 09 ERJ3GEYJ 104 V resistor 022-3906-175
R 11 ERJ3GEYJ 473 V resistor 022-3906-171
R 12 ERJ3GEYJ 102 V resistor 022-3906-154
R 13 ERJ3GEYJ 473 V resistor 022-3906-171
R 14 ERJ3GEYJ 102 V resistor 022-3906-154
R 15 ERJ3GEYJ 473 V resistor 022-3906-171
R 16 ERJ3GEYJ821V resistor 022-3906-153
R 17 EFJ3GEYJ 151 V resistor 022-3906-145
R 18 12K ERJ3GE resistor 022-3906-164
Ref No. Description Part No.
3-KEY ASSEMBLY
EP 1 B-5188B #2176-3D (3-key PC bd) 022-3907-091
C 1 C1608 CH 1H 330J-T-A 022-3906-070
C 2 C1608 CH 1H 330J-T-A 022-3906-070
C 3 C1608 CH 1H 330J-T-A 022-3906-070
C 4 C1608 CH 1H 330J-T-A 022-3906-070
C 5 C1608 CH 1H 330J-T-A 022-3906-070
DS 1 LN1371G-(TR) display/LED 022-3906-098
DS 2 LN1371G-(TR) display/LED 022-3906-098
DS 3 LN1371G-(TR) display/LED 022-3906-098
DS 4 LN1371G-(TR) display/LED 022-3906-098
J 1 AXN720535 022-3906-131
MC 1 EM-123H microphone 022-3906-195
Q 1 2SA1576 S transistor 022-3906-029
R 1 ERJ3GEYJ 333 V resistor 022-3906-169
R 2 ERJ3GEYJ 104 V resistor 022-3906-175
R 3 ERJ3GEYJ 104 V resistor 022-3906-175
R 4 ERJ3GEYJ 104 V resistor 022-3906-175
R 5 ERJ3GEYJ 104 V resistor 022-3906-175
R 6 ERJ3GEYJ 221 V resistor 022-3906-288
R 8 ERJ3GEYJ 103V resistor 022-3906-163
R 10 ERJ3GEYJ 121V resistor 022-3906-144
R 11 ERJ3GEYJ 121V resistor 022-3906-144
R 12 ERJ3GEYJ 103V resistor 022-3906-163
SP 1 EAS3P127J speaker 022-3906-058
W 1 ERDS2T0 resistor to spkr 022-3906-877
W 2 ERDS2T0 resistor to spkr 022-3906-877
W 3 OPC-677 022-3907-069
W 4 OPC-677 022-3907-069
10-KEY ASSEMBLY
EP 1 B-5187C #2176-2D (10-key PC bd) 022-3907-007
C 1 C1608 CH 1H 330J-T-A 022-3906-070
C 2 C1608 CH 1H 330J-T-A 022-3906-070
C 3 C1608 CH 1H 330J-T-A 022-3906-070
C 4 C1608 CH 1H 330J-T-A 022-3906-070
Ref No. Description Part No.
DISPLAY ASSEMBLY
