7-1
November 1999
Part No. 001-7780-500
PARTS LIST
SECTION 7 PARTS LIST
Ref No.
Description
Part No.
CHASSIS PARTS
EP 01
B-3826B #1125-3A (chassis flex)
022-3906-001
EP 02
B-3827C #1125-3B (PTT sw flex) 022-3907-001
F 1
MCA-3 (CCV-3A) fuse
022-3907-037
J 1
3A3-M10 antenna connector
022-3906-124
MP 01
1125 metal chassis-2
022-3906-196
MP 02
1125 top plastic panel (b)-2
022-3907-057
MP 03
1591 top rubber sheet
022-3906-276
MP 04
Screw, 0-1 fh m2x4.5 ni b
022-3907-068
MP 05
VR nut (E)
022-3906-222
MP 06
VR nut (F)
022-3906-223
MP 07
VR nut (I)
022-3906-224
MP 08
1125 top seal
022-3906-271
MP 10
Knob N230 (large)
022-3907-067
MP 12
Knob N231 (small)
022-3907-066
MP 13
1125 accessory jack cover
022-3906-204
MP 16
Screw m2x4.5 zk
022-3906-211
MP 17
Screw B 4
022-3906-212
MP 18
1591 rear plastic panel-1
022-3907-056
MP 22
1591 contact base
022-3906-245
MP 23
1125 battery release button-1
022-3906-228
MP 24
1125 battery release spring-1
022-3906-232
MP 25
1125 plus terminal(A)-1
022-3906-236
MP 26
1591 plus plate
022-3906-246
MP 27
1125 fuse plate
022-3906-237
MP 28
1591 contact pin
022-3906-234
MP 29
Spring (F) rubber contact
022-3906-225
MP 30
1125 minus plate
022-3906-235
MP 32
Screw ph b0 2x4 sus
022-3906-221
MP 33
Screw ph m2x6 sus
022-3906-218
MP 34
Screw ph m2x9 sus
022-3906-219
MP 35
Screw ph m2x23 sus zk
022-3906-220
MP 36
Screw ph 0 m2 x3.5 ni
022-3906-215
MP 37
Screw 1 m2x4.5 zk for RF PA
022-3906-211
MP 39
Screw ph 0 m2 x3.5 ni
022-3906-215
MP 43
Screw ph b0 2x4 sus
022-3906-221
MP 45
Screw ph m2x2.5 zk
022-3906-216
MP 46
1591 RF shield-2
022-3907-063
MP 47
Round stut (G)
022-3906-275
MP 49
1591 antenna jack plate
022-3907-073
MP 50
Himerio-sheet (X)
022-3906-268
MP 52
FCC serial No. sticker (AZ)-1
022-3907-061
MP 59
Insulation plate (BI)
022-3907-071
MP 60
2176 earth plate
022-3907-076
MP 61
Thermal sheet (I)
022-3907-075
MP 62
Rubber sheet (L)
022-3907-072
MP 63
Sponge (cp) srcn
022-3906-269
MP 64
Sponge (BJ)
022-3907-070
JACK ASSEMBLY
J 01
YM-260 accessory jack
022-3906-125
EP 01
B-3829C (#1125-3A) flex circuit
022-3906-003
MP 01
1125 jack panel-1
022-3906-198
MP 02
1125 jack rubber (A)-1
022-3906-238
MP 03
1125 jack plate
022-3906-233
MP 04
Screw ph m2x2.5 zk
022-3906-216
MP 05
1591 jack sheet
022-3906-279
DISPLAY ASSEMBLY
C 1
C1608 CH 1H 330J-T-A
022-3906-070
C 2
680P C1608 B
022-3906-355
C 3
C1608 JB 1C 473K-T-A
022-3906-080
C 4
C1608 JB 1C 104KT-N
022-3906-614
C 5
C1608 CH 1H 330J-T-A
022-3906-070
C 6
C1608 JB 1C 104KT-N
022-3906-614
C 7
C1608 JB 1C 104KT-N
022-3906-614
DS 1
LNG310M6URA LED
022-3906-637
DS 2
LNG310M6URA LED
022-3906-637
DS 3
SEC1601C LED
022-3906-101
DS 4
SEC1401C
022-3906-100
DS 5
SEC 1801C LED
022-3906-102
DS 6
LD-BU10394J
022-3907-036
DS 7
LNG310M6URA LED
022-3906-637
DS 8
LNG310M6URA LED
022-3906-637
EP 1
B-5186A #2176-2D display PC bd
10-key
022-3907-006
B-5186A #2176-3D display PC bd
3-key
022-3907-086
EP 2
SRCN-1125-SG
022-3906-240
EP 3
LCD reflector plate
022-3907-048
Ref No.
Description
Part No.
