TRANSCEIVER PROGRAMMING
3-6
November 1999
Part No. 001-7780-500
3.3.7 HELP MENU
Contents - Displays the help system table of contents.
Search For Help On - Displays the search dialog box
that allows searching for a help topic by keyword.
About PCTrunk - Displays the software version
number of PCTrunk and the address of the E.F.
Johnson Company.
3.4 RADIO-WIDE PARAMETER SCREENS
3.4.1 INTRODUCTION
The radio-wide screens program the parameters
that are the same for all systems, channels, and zones.
Separate screens are used for General, Conventional,
SMARTNET/SmartZone, and Portable Options
parameters. Refer to the information which follows.
3.4.2 RADIO-WIDE GENERAL SCREEN
Band
Displays the operating band selected by the Radio
Type Menu (see Section 3.3.2). The selected oper-
ating band must match that of the radio being
programmed. Currently, only 800 MHz 77xx models
are available.
Zones
Total Zones - The total number of zones currently set
up. The maximum number allowed is 16. Zones are
added by clicking the Add button (see following).
Current Zone - Indicates the currently selected zone.
To select another zone, click the up/down arrows.
Zone Alias - Edits the unique alpha identification for
the displayed zone. Up to 8 characters can be entered.
The zone alias is briefly displayed whenever a new
zone is selected. Refer to Section 1.2.4 for more
information on zones.
Add (Zones) Button - Adds another zone.
Delete (Zones) Button - Deletes the last zone added.
Defaults
Home Zone - Selects the zone that is selected by the
Home Zone option switch if programmed.
Backlight On Time - Selects the length of time that
the backlight stays on after any key or the Backlight
option switch is pressed (see “Options” which fol-
lows and Section 2.3.3).
Options
Backlight Key Press - If checked, the backlight turns
on for the “Backlight On Time” above whenever any
front panel key is pressed (see Section 2.3.3).
Battery Saver - If checked, low transmit power is
automatically selected when the RSSI level indicates
that the site is nearby (see Section 2.3.6).
Keypad Lockout - If checked, all front panel keys are
disabled and are not available to the user (see Section
2.3.5).
Power-Up On Home Zone - If checked, the home
zone is always selected at power-up.
Beeps - If checked, all tones are enabled. Otherwise,
no tones sound (see Section 2.3.10).
