Epson R-D1s - Manual (Page 9)

Getting Started 9
1
1
1
1
1
1
1
1
1
1
Back View
Rangefinder eyepiece
Used to compose your pictures and to focus on the subject.
AE-lock button
Locks the shutter speed at the metered value when using
automatic exposure. (See “Locking the Exposure Setting
(AE-lock)” on page 23 for details.)
Image quality/WB lever
Used when setting image quality or white balance. (See
“Setting White Balance” on page 19 and “Setting Image
Quality” on page 19
for details.)
Memory card access light
Lights when a picture is being saved in the memory card.
Flashes when there is an error or battery is low.
Memory card slot
Accepts an SD memory card of up to 2 GB capacity. (See
“Using a Memory Card” on page 13 for details.)
Memory card slot cover
Protects the memory card and memory card slot.
Focal length conversion table
Lists equivalent 35 mm focal lengths for the attached lenses.
(See “Determining the Effective Focal Length” on page 17
for details.)
