Page 35
Components of 9-wire remote mount transmitter
Figure 4-2:
A
B
C
A. Mounting bracket
B. Cap screws
C. Transmitter
2.
Attach the mounting bracket to an instrument pole.
4.2
Prepare the 9-wire cable
Micro Motion supplies three types of 9-wire cable: jacketed, shielded, and armored. The
type of cable you are using determines how you will prepare the cable.
Perform the cable preparation procedure appropriate for your cable type.
Mounting and sensor wiring for 9-wire remote installations
Installation Manual
31
