Emerson MICRO MOTION 1700 User Manual
Page 109
Recommended pull-up resistor versus supply voltage
Figure 9-15:
3600
3200
2800
2400
2000
1600
1200
800
0
5
10
15
20
25
30
Supply voltage (Volts)
External pull-up resistor range (Ohms)
4000
4400
9.4.3
Internally powered discrete output wiring on Channel C
Internally powered discrete output wiring on Channel C
Figure 9-16:
A
A.
Total load
I/O wiring for Model 2700 transmitters with configurable input/outputs
Installation Manual
105
