9.4.2 Externally powered discrete output wiring on Channel B
Externally powered discrete output wiring on Channel B Figure 9-14:
A
B
A. 3–30 VDC
B. Pull-up resistor or DC relay
CAUTION!
Exceeding 30 VDC can damage the transmitter. Terminal current must be less than 500 mA.
I/O wiring for Model 2700 transmitters with configurable input/outputs
104 Micro Motion ® Model 1700 and 2700
