SURFACE CONTROLS
28
The MC Control has four channel strips each with a touch-sensitive fader, eight
touch-sensitive knobs surrounding a 7-in touchscreen, twelve soft keys, trans-
port switches, a Jog wheel, and various navigation buttons.
The MC Control comes with an external DC power supply. Rear panel jacks in-
clude: DC power input, RJ-45 Ethernet, and ¼-in footswitch.
4.1 Power Switch
Press and release the POWER switch to turn the MC Control on/off.
• The Touchscreen shows a Euphonix logo upon power up.
• All activity on the Touchscreen ceases upon power down.
4.2 Shift Key
The Shift key is used in conjunction with other keys to access the functions la-
beled in
blue above the primary function. Press and hold the Shift key, found at
the MC Control’s bottom-left and -right, then press the other key.
The User Guide uses the following simplified terminology to describe Shift func-
tions: “press the Shift
+ APPLICATION keys” is written as “press the WORKSTATION
key.”
The Shift key can be locked on like caps lock on a computer keyboard by press-
ing both Shift keys simultaneously. This is useful if you plan to access several
Shift functions consecutively. Press either Shift key to unlock.
