55

U

SE

UPS

C

ONFIGURATION

The following table illustrates all the possible configurations that users have at their disposal to best adapt
the UPS to their needs.

LEGEND:


Indicates that the configuration can be modified, both via the configuration
software supplied and also by means of action on the display panel.


Indicates that the configuration can be modified only through the configuration
software supplied.

FUNCTION

DESCRIPTION

PREDEFINED

POSSIBLE CONFIGURATIONS

MODE

Output frequency

Selects the nominal

output frequency

Auto

50 Hz
60 Hz
Auto: automatic self-teaching of the

input frequency

Output voltage

Selects the nominal

output voltage

230V

220V
230V
240V
220 ÷ 240 in steps of 1V

(only through the software)

Operating mode

Selects one of the 4

different modes of

operation

ON LINE

ON LINE
ECO
SMART ACTIVE
STAND-BY OFF

Switch-on delay

Delay time for

automatic switching

on again after the

mains returns

5 sec.

Disabled
1 ÷ 255 in steps of 1 sec.

Switch-off due to

minimum load

Automatic UPS

switch-off when in

battery-powered

operation, if the load

is less than 5%

Disabled

Enabled
Disabled

Back-up

limitation

Maximum battery

operation time

Disabled

Disabled (full battery discharge)
1 ÷ 65000 in steps of 1 sec.

End of discharge

early warning

Estimated remaining

back-up time for the

end of discharge early

warning

3 min.

1 ÷ 255 in steps of 1 min.

=

=
