P
RESENTATION
The new Sentinel Dual UPS family has been designed with a special eye to versatility. These UPS,
depending on the user’s requirements, can in fact be installed either in tower version or in rack version (by
means of a suitable handles kit option). The 2 different product versions are shown below:
The UPS also has a dedicated battery pack that permits easy replacement of the batteries (hot swap), entirely
safely for the operator, thanks to the protected connection system.
SDL 3300 SDL 4000
Nominal power [VA] 3300 4000
Nominal voltage [Vac] 220 / 230 / 240
Dimensions H x L x D [mm] 455 x 175 x 520 (1)
Weight [Kg] 38
(1)
In the rack version, with the handles installed, the H dimension changes as follows: 483mm x 175mm x 520mm (H x
L x D)
Note: 175mm = 4U
483mm = 19”
Tower Rack
