43
C
ONTENTS
P
RESENTATION
44
UPS VIEWS 45
DISPLAY MASK VIEW 46
I
NSTALLATION
47
O PENING THE PACKING AND CHECKING CONTENTS 47
TOWER VERSION 48
RACK VERSION 49
U
SE
50
C ONNECTIONS AND SWITCHING ON FOR THE FIRST TIME 50
S WITCHING ON FROM THE MAINS 50
S WITCHING ON FROM THE BATTERY 50
S WITCHING THE UPS OFF 50
D ISPLAY P ANEL I NDICATIONS 51
UPS status indicators 51
Measurements display area 52
Configuration area 53
M ODES OF OPERATION 54
UPS C ONFIGURATION 55
C OMMUNICATION PORTS 57
RS232 and USB connectors 57
Communication Slot 57
S OFTWARE 58
Monitoring and control software 58
Configuration software 58
B
ATTERY PACK
59
R EPLACEMENT OF THE BATTERY PACK 59
P
ROBLEM SOLVING
60
A LARM CODES 62
T
ECHNICAL DATA TABLE
64
F
ERRITE INSTALLATION ADDENDUM
65
