i-WATCHER Installation Method 3:
Internet Access Mode:
Dial-up ADSL or Cable Modem
Real IP Address:
A dynamic IP address provided by the ISP
IP Sharing or LAN Hub:
Enable DHCP and NAT function
i-WATCHER Network Setup:
LAN Enable (Manually)
Web Server Port Number(setting required)
User:
ADSL dial-up user who installed multiple
i-WATCHER with a dynamic IP address
z
Activate PPPoE auto dial-up and connect to ADSL function of the IP sharing switch.
Assign another Private IP address, enable the DHCP. Upon successful ADSL connection,
a dynamic IP address will be allocated from the ISP
z
In each i-WATCHER IP address settings, assign each with different virtual IP addresses,
as well as different port number for the HTTP Port setting.
z
For the setting of the Port switching in the IP sharing switch, please refer to the IP-Cam’s
IP address and the Port sequence synchronization setting.
z
For remote viewing of i-WATCHER: launch IE browser and enter the ADSL acquired
dynamic IP address and the i-WATCHER’s Port number
