Edelbrock 2010 User Manual
Page 6

©2013 Edelbrock LLC
Part #1596, 1597, 1598, 1599
Brochure #63-1598
Rev. 3/25/13 - QT/mc
Edelbrock E-Force Supercharger System for
the 2010-2013 Camaro SS
Installation Instructions
Page 5
Bag #3
(11x) - M8 x 1.25 x 25mm
Countersunk Socket Head Bolt
(8x) - M6 x 1 x 45mm
Hex Flange Bolt
(4x) - M6 x 1 x 12mm
Socket Head Bolt
(1x) - 15/64” High Speed Steel Drill Bit
(1x) - .2500” Reamer
Bag #4
(1x) - M16 x 2 x 120mm Hex Bolt
(1x) - GM Factory Harmonic Balancer Bolt
Drill Hole
Ream Hole
Bolt Hole
(1x) - 1/4” x 3/4”
Steel Dowel
(1x) - Crank Pinning Drill Guide
(2x) - M6 x 1 x 16mm
Button Head Bolt
