23552-4-0408 Page 7
Remote Control Options
& Accessories
Description
FRBC Millivolt Battery Remote ON/OFF
FRBTC Millivolt Battery Remote Thermostat
FREC Direct Ignition/Millivolt 120V ON/OFF Remote
TMW Millivolt Wireless Wall Thermostat
TRW Millivolt Reed Switch Wall Thermostat
FWS-1 Direct Ignition/Millivolt Wall Switch
Venting Options Description
DVVK-4TSP
(DVVK-4TS)
Top vent kit (horizontal) - 4½" to 6" (114.3 mm to 152 mm) wall thickness
DVVK-4TP
(DVVK-4T)
Top vent kit (horizontal) - 8" to 12" (203 mm to 305 mm) wall thickness
DVVK-4RP
(DVVK-4R)
Rear vent kit (horizontal) - 5" to 7" (127 mm to 178 mm) wall thickness
DVVK-4VP
(DVVK-4V)
Vertical vent kit
DVVK-4F Horizontal flex vent kit (4' FLEX)
DVVK-4RE Horizontal round termination (wall thickness up to 11 7/16")
DV822 Vinyl siding kit for DVVK-4RE
DVD32 DVD36 DVD42 DVD48
Input BTU/Hr Maximum 18,000 20,000 25,000 28,000
BTU/Hr Minimum (millivolt only) 14,000 14,000 18,000 20,000
KWH (Maximum) 5.3 5.9 7.3 8.2
(Minimum) 4.1 4.1 5.3 5.9
NAT.
Orifice
#46 (.081")
P-254
2.10 mm
P-288
#42 (.0935")
P-286
#39 (.0995")
P-285
Air Shutter Opening 1/16" (1.6 mm) 1/16" (1.6 mm) 3/16"(4.8 mm) 1/8" (3.2 mm)
LP
Orifice
#56 (.0465")
P-287
#55 (.052")
P-182
1.45 mm
P-208
#52 (.0635")
P-185
Air Shutter Opening 1/4" (6.3 mm) 5/16" (7.9 mm) 5/16" (7.9 mm)
5/16"
(7.9 mm)
Height without standoff 32 3/4" (832 mm) 32 3/4"(832 mm) 34 3/4"(883 mm)
34
3/4"(883 mm)
Width 34" (864 mm) 37" (940 mm) 43" (1092 mm)
49"
(1245 mm)
Depth 16 3/8" (416 mm) 16 3/8" (416 mm) 16 3/8" (416 mm)
16 3/8"
(416 mm)
Gas Inlet Shutoff Valve (Pipe) 1/2 NPT 1/2 NPT 1/2 NPT 1/2NPT
NOTE: Air shutter settings are factory minimum settings. Some venting configurations may require minor air
shutter adjustments for optimum performance.
SPECIFICATIONS
