Evo Fitness FX40HR User Manual
Page 7
FX40HR MOTORIZED TREADMILL
Visit us at: www.evofitness.com
7
PARTS LIST
NO. DESCRIPTION
QTY. ORDER NO.
NO. DESCRIPTION
QTY.
ORDER NO.
57
6.5 x 13mm Washer
5
FX40-57
85
M6 x 70mm Screw
3
FX40-85
58
Side Rail
2
FX40-58
86
Deck Cushion
8
FX40-86
59
Deck End Cap - Left
1
FX40-59
87
Front Roller with
Flywheel 1
FX40-87
60
Deck End Cap - Right 1
FX40-60
88
Front Roller Shaft
1
FX40-88
61
Running Belt
1
FX40-61
89
Fame Cover - Right
1
FX40-89
62
Rail Guide
8
FX40-62
90
10mm Shaft
1
FX40-90
63
M8 x 25mm Screw
8
FX40-63
91
Bushing
2
FX40-91
64
Running Deck
1
FX40-64
92
Plastic Clamp - Top
2
FX40-92
65
Washer
2
FX40-65
93
Plastic Clamp - Bottom
2
FX40-93
66 Rubber
Cushion
1
FX40-66
94 Bracket
2
FX40-94
67
M8 x 135mm Bolt
1
FX40-67
95
M10 x 90mm Screw
1
FX40-95
68
Motor Bracket
1
FX40-68
96
Spring Washer
8
FX40-96
69
M8 x 15mm Screw
2
FX40-69
97
Rear Roller
1
FX40-97
70
Spring Washer
2
FX40-70
98
Rear Roller Shaft
1
FX40-98
71
8 x 16mm Washer
2
FX40-71
99
M8 Nut
8
FX40-99
72
M10 x 136mm Hex
Bolt
1 FX40-72
100
M8 x 19mm Allen Head
Bolt
4 FX40-100
73
Driving Motor
1
FX40-73
101
Deck Wheel
2
FX40-101
74
Motor Drive Belt
1
FX40-74
102
M8 x 43mm Bolt
2
FX40-102
75
Elevation Motor
1
FX40-75
103
Motor Belly Pan
1
FX40-103
76
Clip
2
FX40-76
104
M8 x 35mm Screw
3
FX40-104
77
M5 x 12mm Screw
2
FX40-77
105
Elevation Support Tube
Cover - Left
1
FX40-105
78
M10 x 63mm Bolt
1
FX40-78
106
Deck Frame
1
FX40-106
79
Motor Control Board
1
FX40-79
107
Cap
2
FX40-107
80
Transformer Board
1
FX40-80
108
Rubber Cushion
2
FX40-108
81
M10 x 35mm Screw
9
FX40-81
109
M8 x 76mm Bolt
2
FX40-109
82
Elevation Support
1
FX40-82
110
Metal Cap
2
FX40-110
83
Micro Switch
1
FX40-83
111
Cross Brace
1
FX40-111
84
Frame Cover - Left
1
FX40-84
112
N/A
