FX40HR MOTORIZED TREADMILL
Visit us at: www.evofitness.com
6
PARTS LIST
NO. DESCRIPTION
QTY. ORDER NO.
NO. DESCRIPTION
QTY.
ORDER NO.
1
N/A
29
6.5 x 13mm Washer
1
FX40-29
2
Console
1
FX40-02
30
Fold Up Lock
1
FX40-30
3
Top Console Housing
1
FX40-03
31
Spring
1
FX40-31
4
Bottom Console
Housing
1
FX40-04
32
Base Frame End Cap
2
FX40-32
5
Wire Protection Ring
1
FX40-05
33
Level Adjust
2
FX40-33
6
Safety Key
1
FX40-06
34
Base Frame
1
FX40-34
7
M4 x 12mm Screw
17
FX40-07
35
Rear Moving Wheel
2
FX40-35
8
Console Support
Tube
1 FX40-08
36
Cushion
4 FX40-36
9
M6 x 15mm Screw
4
FX40-09
37
Cap
1
FX40-37
10
Handlebar Front End
Cap
2
FX40-10
38
3/8” x 30mm Bolt
1
FX40-38
11
Motion Control
Sensor
2 FX40-11
39
Bushing
1 FX40-39
12
Hand Pulse Sensor
2
FX40-12
40
Wheel
1
FX40-40
13
M8 x 50 Allen Head
Bolt
6
FX40-13
41
Deck Frame Support
1
FX40-41
14
Handlebar - Left
1
FX40-14
42
Shock
1
FX40-42
15
Handlebar - Right
1
FX40-15
43
C Clip
2
FX40-43
16
Plastic Fixing Insert
6
FX40-16
44
4.5 x 12mm Washer
8
FX40-44
17
#8 x 25 Screw
8
FX40-17
45
M8 x 15mm Screw
30
FX40-45
18
M5 x 10mm Allen
Head Bolt
1
FX40-18
46
M10 Nylon Nut
5
FX40-46
19
Left Upright
1
FX40-19
47
M8 x 40mm Bolt
1
FX40-47
20 Right
Upright
1
FX40-20
48 N/A
N/A N/A
21
Plastic Cover
2
FX40-21
49
M8 Nylon Nut
2
FX40-49
22
M6 x 20mm Screw
2
FX40-22
50
M10 x 60mm Bolt
2
FX40-50
23
M8 x 15mm Bolt
8
FX40-23
51
Caster Wheel - Front
2
FX40-51
24
M5 x 8mm Bolt
2
FX40-24
52
Caster Bracket
1
FX40-52
25 Switch
Plate
1
FX40-25
53 N/A
26
M14 x 90mm Bolt
2
FX40-26
54
Motor Hood Insert
1
FX40-54
27
Elevation Support
Tube Cover - Right
1
FX40-27
55
Motor Hood
1
FX40-55
28
M5 x 10mm Screw
1
FX40-28
56
M8 x 50mm Screw
2
FX40-56
