FX40HR MOTORIZED TREADMILL
Visit us at: www.evofitness.com
11
ASSEMBLY
STEP 1:
Remove your treadmill from the carton and place it on the floor in an open area as shown in FIG-1. Then remove the
Handlebar and place them out of the way for now, as shown in FIG2.
Rotate the Console Housing to the correct position then secure with two M6 x 55mm Bolt (132).
132
4
8
